Technical Characteristics:
- Rating: 415 Vac,3phase,50hz,Max. Switching Frequency 720 Per Hr.
- Gas Group: Iia,Iib,Iic ,Epl Gb &Db Atmosphere As Per Is/Iec 60079-1:2014,Ex "D"
- Zone: Zone 1 & 2
- Deg. Of .Prot: Ip:66 As Per Is/Iec 60529-2001(Reformed 2014)
- Temp. Class: T6
- Cimfr Cert. No. : In/Cimfr/Tr20/540 Dtd. 14/02/2020
- Peso Cert. No. : A/P/Hq/Mh/104/7559 (P559440/2) Dtd. 10/04/2023
- Bis Cert. No. :Cm/L-7800028013 Dtd. 27/09/2016
- Paint: Epoxy Smoke Grey
- Note: Oil For Thrustor : Transformer Oil Bs148 Or Equivalent
Technical Characteristics:
- Rating: 415 Vac,3phase,50hz,Max. Switching Frequency 720 Per Hr.
- Gas Group: Iia,Iib,Iic ,Epl Gb &Db Atmosphere As Per Is/Iec 60079-1:2014,Ex "D"
- Zone: Zone 1 & 2
- Deg. Of .Prot: Ip:66 As Per Is/Iec 60529-2001(Reformed 2014)
- Temp. Class: T6
- Cimfr Cert. No. : In/Cimfr/Tr20/540 Dtd. 14/02/2020
- Peso Cert. No. For 34kg : A/P/Hq/Mh/104/7559 (P559440/4) Dtd. 10/04/2023
- Peso Cert. No. For 46kg : A/P/Hq/Mh/104/7559 (P559440/1) Dtd. 10/04/2023
- Bis Cert. No. :
- Paint: Epoxy Smoke Grey
- Note: Oil For Thrustor : Transformer Oil Bs148 Or Equivalent
