| Max Cable Length | 25 m |
|---|---|
| Material | Ms And As Per Rquirment |
| Surface Treatment | Vertical And Horizontal |
| Brand | Labh Enginnering |
| Usage/Application | Eot Crane And Transfer Trolley |
| Country of Origin | Made in India |
| Minimum order quantity | 1 Piece |
Motorized Cable Reeling DrumThe Motorized Cable Reeling Drums, offered by us are supports various cables reeling applications. Powered with springs and supported by automatic rewind feature, these reeling drums serves as simple source of power supply to machines like cranes and hoists
Technical Data:
- Body Material: Black 15% Glass Filled Nylon
- Cover Material: Orange ABS Plastic
- Gear Ratio: 1:12.5, 1:25, 1:50, 1:100, 1:200 & 1:400
- No of Contacts: 2NC or 1NO + 1NC
- Ampere: 10Amps
- Voltage: 500V AC
- Protection: IP 65 as per IEC 60529:2013
- Temperature: -25° C to 50° C
- Mounting Position: Any position
- Contact Material: Brass Material with Nickle Plated & Silver cadmium tip
- Connection: Screw terminal type
